This premium Aqua-Flo by Gecko Flo-Master XP2e replacement pump arrives as original equipment in numerous spa brands and offers straightforward installation for those comfortable with basic maintenance tasks.
Technical Specifications: This is a 56 frame XP2e 3.0HP 230V Side Discharge wet end configuration featuring 2" suction and 2" pressure connections measuring approximately 3" edge to edge. Electrical draw is 12 Amps at High Speed and 4.4 Amps at Low Speed, delivering full 3.0 Horse Power performance.
Voltage Verification Important: Confirm your voltage requirements by examining the pump label (will display either 115V or 230V) or by locating the white wire connection in your control pack if the label isn't visible. For 230V operation, the white wire connects to the red leg or #2 leg; for 115V, it connects to the Neutral or White AC leg. Always disconnect the spa breaker before performing any electrical inspections.
About the XP2e Series: Aqua-Flo by Gecko's Flo-Master XP2e represents their energy-efficient solution within the high performance spa pump category. Engineered specifically for contemporary large-capacity spas with extensive jet arrays demanding elevated flow rates, the XP2e maintains the same physical footprint as the original XP2 while delivering superior flow and enhanced overall energy efficiency.
Key Pump Benefits:
- Precision-engineered impeller optimized for maximum water movement and performance
- 2" intake and discharge ports
- Robust 56-frame motor construction
- Thermal protection for extended component life
- Energy-efficient design reduces operational costs
- Drop-in replacement compatibility with original XP2 footprint
This jet pump delivers the power and reliability needed for heavily jetted spa systems while maintaining energy-conscious operation. Perfect for spa owners seeking factory-grade replacement components with improved efficiency characteristics.
