This part is a Sta-Rite Dura-Jet Complete 2" X 2" Wet End that fits both 48 or 56 frame motors and would fit a 230V Pump that is 8.0 Amps or a 115V pump that is 12.0 Amps..
The 2" fitting actually measures about 3" Edge to Edge across the threads..
It features 3 cast in Bleeder Barb connections that are sealed up and will require drilling to use.. (2) at the suction fitting and (1) at the pressure side fitting..
| Manufacturer | Balboa Water Group |
| Pump Model | Dura-Jet DJ Series |
| Motor Frame | 48 Frame Thru-Bolt, 56 Frame Thru-Bolt |
| Drain Plug Location | 3,6,9 o`clock |
| Suction Style | Center |
| Suction Connection Type | Male Buttress Thread (mbt) |
| Suction Pipe Size | 2" |
| Discharge Style | Side |
| Discharge Connection Type | Male Buttress Thread (mbt) |
| Discharge Pipe Size | 2" |
| Horsepower | 1.0hp |
| Volute Fastening Type | 4 Bolts and 4 Nuts |
