Rare Vico / Balboa Ultima 2.0 HP, 230 Volt, 56 frame spa pump assembly in 2 speed. This side discharge pump has 2" unions that measure 3" across the male threads. Most Ultima pumps are 48 frame but this model uses an adapter plate to adapt the 48 frame wetend to the larger 56 frame motor. The Ultima models look similar to the Ultimax, but instead of having 5 bolts in the wetend face like the Ultimax, the Ultima has 4 bolts.
| Motor Voltage | 230v |
| Speed | 2 Speed (2-Spd) |
| Motor Amperage/Wattage | 8.8A/2.6A |
| Horsepower | 2.0hp |
| Manufacturer | Vico/Balboa |
| Pump Model | Ultima |
| Suction Pipe Size | 2" |
| Suction Connection Type | Male Buttress Thread (mbt) |
| Suction Style | Center |
| Discharge Pipe Size | 2" |
| Discharge Connection Type | Male Buttress Thread (mbt) |
| Discharge Style | Side |
| Motor Frame | 56 Frame Thru-Bolt |
IMPORTANT MOTOR VARIATION NOTICE
Due to ongoing changes in the hot tub pump industry since COVID, motor appearance and configuration may vary, even when the part number is the same. While the pump wet end will be correct, the motor may differ in areas such as capacitor location, labeling, or housing.
If you have a specific motor requirement (clearance, capacitor position, orientation, etc.), you must contact us before ordering so we can verify availability. Do not order first and contact us after delivery due to appearance differences.
Motor variations are outside of our control and may change week to week. Appearance differences do not constitute an incorrect item if specifications are met.
